| Target: | Refrigerant, benzene, alcohol &etc. |
| Model: | WSP5110 |
| Detection range: | 10～1000ppm |
| Detection principle: | Semiconductor |
| Characteristics: | High sensitivity to Refrigerants; quick response and resume; low power consumption, simple detection circuit, good stability and long life. |
WSP5110 Manual download
Get Price Whatsapp
Description
WSP5110 Refrigerant detection gas sensor adopts multilayer thick film manufacturing technology. The heater and metal oxide semiconductor material on the ceramic substrate of subminiature Al2O3 are fetched out by electrode down-lead, encapsulated in metal socket and cap. Conductivity of the sensor is affected by the concentration of target gas. The higher the concentration is, the higher conductivity of sensor gets. Users can adopt simple circuit to convert variation of conductivity into output signal corresponding to gas concentration.
Application
It is widely used in home, environmental occasions for Refrigerant detection.
Features
High sensitivity to Refrigerants; quick response and resume; low power consumption, simple detection circuit, good stability and long life.
Specifications
| Model | WSP5110 | ||
| Sensor Type | Semiconductor flat surfaced sensor | ||
| Standard Encapsulation | Metal Cap | ||
| Detection Gas | Refrigerant, benzene, alcohol &etc. | ||
| Detection range | 10～1000ppm | ||
| Standard circuit | Loop voltage | VC | ≤24V DC |
| Heating voltage | VH | 5.0V±0.1V AC or DC | |
| Load resistance | RL | Adjustable | |
| sensor features in standard test condition | Heating resistance | RH | 90Ω±10Ω(Room Temperature) |
| Heating consumption | PH | ≤300mW | |
| Surface resistance | RS | 30KΩ～200KΩ(in 100ppm Refrigerant) | |
| Sensitivity | S | Rs(in air)/Rs(in 100ppm Refrigerant)≥3 | |
| Concentration slope | α | ≤0.65(R200ppm/R50ppm refrigerant) | |
| Standard condition of test | Temperature, humidity | 20℃±2℃；65%±5%RH | |
| Standard test circuit | Vc:5.0V±0.1V； VH:5.0V±0.1V | ||
| Warm-up time | Not lessthan120 hours | ||
| Life Span | 10 years | ||
* The description and specifications might be changed without notice. Please contact us for the latest information before placing orders.
Technical Support:
Customized technical design and function, LOGO and package are available without extra charge (including molding fee) for mass volume.
The sensors don't have sleeping mode. It can be set in program if needed.
All Winsen products go through strict inspections and tests to make sure they are 100% qualified before shipping out.
The sensor has been fully tested (not calibrated) before leaving the factory. However, after transportation and storage, the environment conditions change, and the surface of the sensor absorbs moisture, mixed gas, pollution matters, etc. It is recommended that customers perform aging and calibration after sensors become stable according to the program and use occasions of the whole device.
15﹪-90﹪RH without condensation,greater or less than this range or long-term high temperature and high humidity will affect the life of the sensor.
Our sensors are certified with CE, 3C, ROHS, anti-explosion, fire prevention, and coal mining safety according to different applications. And we provide assistance for new certification.
Many factors can cause the sensor to fail such as broken wires in transportation, poisoning, falling off of the sensitive material, damage to the heating wire (device), etc. Please find specific cause in each category with Winsen’s aftersales.
