Automotive

Make your car more comfortable, safe, and intelligent!

With the rapid development of the new energy automobile industry, the requirements for electronization, automation and intelligence of automobiles are becoming higher and higher. Winsen has passed IATF 16949 Automotive Quality Management System Certification, and has obtained supply qualifications from many well-known automobile manufacturers.

Automotive Sensor Solution include three series of sensor products, such as comfort, safety, and intelligence, providing perfect solutions for automobiles with excellent performance, reliable quality and professional technical service..

Comfort Product Line

Winsen developed automotive comfort products, such as Air Quality Sensor (AQS), Carbon Dioxide Sensor (CO2), PM2.5 Single/Dual Channel Laser Dust Sensor and All-in-one Air Quality Sensor, which can be widely used in traditional and new energy vehicles. They can detect the air quality inside and outside the car in real time, providing passengers with a healthier and more comfortable environment.

ZM102 AQS Air Quality Sensor for Automotive
ZM102 AQS Air Quality Sensor for Automotive
  • CO/HC、NOx、NH3
  • Read More
MH-V1512A NDIR CO2 Sensor for Automotive
MH-V1512A NDIR CO2 Sensor for Automotive
  • CO2
  • 400~10000ppm optional
  • Read More
ZH30/ZH32- Single/Dual Channel Laser Dust Sensor (PM2.5)
ZH30/ZH32- Single/Dual Channel Laser Dust Sensor (PM2.5)
  • PM1.0,PM2.5,PM10
  • 0-1000μg/m³
  • Read More
ZMHS10- All-in-one Air Quality Sensor
ZMHS10- All-in-one Air Quality Sensor
  • PM2.5, CO2, AQS, Temperature and humidity
  • PM2.5:0~1000μg/m³
    CO2:400~10000ppm
    AQS:CO: 1~5000ppm, NOx: 0~10ppm, NH3: 1~300ppm
    Temperature:-40~125℃
    Humidity:0~100%RH
  • Read More

Safety Product Line

Winsen developed automotive safety products, such as Hydrogen Leak Sensor, On-line Water Conductivity Sensor, Lithium Battery Thermal Runaway All-in-one Sensor, and Alcohol Detection Sensor. They can sense early, make intelligent judgments, and intervene in advance to avoid unnecessary car safety accidents.

ZC61 vehicle hydrogen leakage detection sensor
ZC61 vehicle hydrogen leakage detection sensor
  • Hydrogen (H2)
  • 0-40000ppm
  • Read More
ZC41- Natural Gas Leak Sensor (CH4)
ZC41- Natural Gas Leak Sensor (CH4)
  • Natural gas, liquefied gas, coal gas, alkanes and other flammable gases
  • 0~100%LEL
  • Read More
ZEQH-101- All-in-one Lithium Battery Thermal Runaway Sensor
ZEQH-101- All-in-one Lithium Battery Thermal Runaway Sensor
  • CO, CO2, VOC, temperature, pressure
  • CO:0~1000ppm
    CO2:400~10000ppm
    VOC:200~10000ppm
    Pressure:0 ~130kPa
    Temperature:-40℃~200℃
  • Read More
ZPH07- Lithium Battery Aerosol Monitoring Sensor
ZPH07- Lithium Battery Aerosol Monitoring Sensor
  • Aerosol
  • 0~10000μg/m³
  • Read More
ZW-HC101- On-line Water Conductivity Sensor
ZW-HC101- On-line Water Conductivity Sensor
  • Coolant
  • 0.01~20 uS/cm
  • Read More
Alcohol Detection Sensor
Alcohol Detection Sensor
  • Alcohol
  • 0~440mg/100ml(0~2mg/L)
  • Read More

Intelligence Product Line

Winsen developed automotive intelligent products, such as Light and Rainfall Composite Sensor, Life Legacy Sensor, and Anti-intrusion Sensor, greatly enhance the electronic and intelligent level of cars, and further improve vehicle safety and intelligent configuration.

ZH101- Light and Rainfall Composite Sensor
ZH101- Light and Rainfall Composite Sensor
  • Water & Light
  • Rainfall:7*7mm(Rainfall detection area)
    Lighting directly above:1000~50000lx(Light intensity detection range)
    Front light:1000~100000lx(Light intensity detection range)
    Temperature:-40~85℃
    Humidity:0~100%RH
  • Read More
ZH401- Light Sensor
ZH401- Light Sensor
  • Light
  • 1500~6000lx
  • Read More
ZHMT101- Life Legacy Sensor
ZHMT101- Life Legacy Sensor
  • Life form
  • Detection field of view range:0.6*1.4*0.6m
    CO2:400~5000ppm
    Temperature:-55~125℃
  • Read More
Anti-intrusion Sensor
Anti-intrusion Sensor
  • Life form
  • Detection distance:3m
    Temperature:-55~125℃
  • Read More

Help you compare our sensors

Table Overview for Winsen CO2 sensor

Unsure which sensor to choose, please leave your information or email us sales@winsensor.com

Table Overview for Comfort Product Line

Model Detection principle Detection object Detection range Output mode

ZM102
MOS CO/HC, NOx, NH3 CO: 1~5000ppm NOx: 0~10ppm NH3: 1~300ppm LIN/PWM(Customizable)

MH-V1512A
NDIR CO2 400~10000ppm optional LIN/PWM(Customizable)

ZH30/ZH32
Mie scattering principle 0.3~10μm dust particles 0~1000μg/m³ CAN/LIN(Customizable)

ZMHS10
Mie scattering principle, NDIR, MOS, Temperature sensing circuit, humidity sensing material and so on PM2.5, CO2, AQS, Temperature and humidity PM2.5:0~1000μg/m³ CO2:400~10000ppm AQS:CO: 1~5000ppm、NOx: 0~10ppm, NH3: 1~300ppm Temperature:-40~125℃ Humidity:0~100%RH CAN/LIN(Customizable)

Table Overview for Safety Product Line

Model Detection principle Detection object Detection range Output mode

ZC61
Catalytic combustion H2 0~40000ppm PWM/CAN/Analog quantity(Customizable)

ZC41
Catalytic combustion Natural gas, liquefied gas, coal gas, alkanes and other flammable gases 0~100%LEL PWM/CAN/Analog quantity(Customizable)

ZEQH-101
Planar semiconductor NDIR CO, CO2, VOC, temperature, pressure CO:0~1000ppm CO2:400~10000ppm VOC:200~10000ppm pressure:0~130kPa temperature:-40℃~200℃ CAN/LIN(Customizable)

ZPH07
Infrared light scattering Aerosol 0~10000μg/m³ CAN/LIN(Customizable)

ZW-HC101
Electrochemistry Coolant 0.01~20 uS/cm CAN/Analog quantity(Customizable)

Alcohol Detection Sensor
Electrochemistry Alcohol 0~440mg/100ml(0~2mg/L) CAN/LIN(Customizable)

Table Overview for Intelligence Product Line

Model Detection principle Detection object Detection range Output mode

ZH101
Total reflection of light Water & Light Rainfall:7*7mm(Rainfall detection area) Lighting directly above:1000~50000lx(Light intensity detection range) front light:1000~100000lx(Light intensity detection range) temperature:-40~85℃ humidity:0~100%RH CAN/LIN(Customizable)

ZH401
Photoelectric conversion Light 1500~6000lx Low level/ High resistance state(Customizable)

ZHMT101
Infrared thermopile NDIR Life form Detection field of view range:0.6*1.4*0.6m CO2:400~5000ppm temperature:-55~125℃ CAN/LIN(Customizable)

Anti-intrusion Sensor
Infrared pyroelectricity Life form Detection distance:3m temperature:-55~125℃ CAN/LIN(Customizable)
