ZM102 Vehicle air quality sensor
ZM102 Vehicle air quality sensor
  • CO/HC、NOx、NH3
  • Read More
MH-V1512A NDIR CO2 Sensor
MH-V1512A NDIR CO2 Sensor
  • CO2
  • 400~10000ppm optional
  • Read More
ZH30/ZH32- Single/Dual Channel Laser Dust Sensor (PM2.5)
ZH30/ZH32- Single/Dual Channel Laser Dust Sensor (PM2.5)
  • PM1.0,PM2.5,PM10
  • 0-1000μg/m³
  • Read More
ZMHS10- All-in-one Air Quality Sensor
ZMHS10- All-in-one Air Quality Sensor
  • PM2.5, CO2, AQS, Temperature and humidity
  • PM2.5:0~1000μg/m³
    CO2:400~10000ppm
    AQS:CO: 1~5000ppm, NOx: 0~10ppm, NH3: 1~300ppm
    Temperature:-40~125℃
    Humidity:0~100%RH
  • Read More
ZC61 vehicle hydrogen leakage detection sensor
ZC61 vehicle hydrogen leakage detection sensor
  • Hydrogen (H2)
  • 0-40000ppm
  • Read More
ZC401- Natural Gas Leak Sensor (CH4)
ZC401- Natural Gas Leak Sensor (CH4)
  • Natural gas, liquefied gas, coal gas, alkanes and other flammable gases
  • 0~100%LEL
  • Read More
ZEQH-101- All-in-one Lithium Battery Thermal Runaway Sensor
ZEQH-101- All-in-one Lithium Battery Thermal Runaway Sensor
  • CO, CO2, VOC, temperature, pressure
  • CO:0~1000ppm
    CO2:400~10000ppm
    VOC:200~10000ppm
    Pressure:0 ~130kPa
    Temperature:-40℃~200℃
  • Read More
ZPH07- Lithium Battery Aerosol Monitoring Sensor
ZPH07- Lithium Battery Aerosol Monitoring Sensor
  • Aerosol
  • 0~10000μg/m³
  • Read More
ZW-HC101- On-line Conductivity Sensor
ZW-HC101- On-line Conductivity Sensor
  • Coolant Conductivity
  • 0.01~20 uS/cm
  • Read More
Alcohol Detection Sensor
Alcohol Detection Sensor
  • Alcohol
  • 0~440mg/100ml(0~2mg/L)
  • Read More
ZH101- Light and Rainfall Composite Sensor
ZH101- Light and Rainfall Composite Sensor
  • Water & Light
  • Rainfall:7*7mm(Rainfall detection area)
    Lighting directly above:1000~50000lx(Light intensity detection range)
    Front light:1000~100000lx(Light intensity detection range)
    Temperature:-40~85℃
    Humidity:0~100%RH
  • Read More
ZH401- Light Sensor
ZH401- Light Sensor
  • Light
  • 1500~6000lx
  • Read More
ZHMT101- Life Presence Sensor
ZHMT101- Life Presence Sensor
  • Life form
  • Detection field of view range:0.6*1.4*0.6m
    CO2:400~5000ppm
    Temperature:-55~125℃
  • Read More
Anti-intrusion Sensor
Anti-intrusion Sensor
  • Life form
  • Detection distance:3m
    Temperature:-55~125℃
  • Read More

Help you compare our sensors

Table Overview for Winsen Automotive Sensor

Unsure which sensor to choose, please leave your information or email us sales@winsensor.com

Comfort Product Line

Model Detection principle Detection object Detection range Output mode

ZM102
MOS CO/HC, NOx, NH3 CO: 1~5000ppm NOx: 0~10ppm NH3: 1~300ppm LIN/PWM(Customizable)

MH-V1512A
NDIR CO2 400~10000ppm optional LIN/PWM(Customizable)

ZH30/ZH32
Mie scattering principle 0.3~10μm dust particles 0~1000μg/m³ CAN/LIN(Customizable)

ZMHS10
Mie scattering principle, NDIR, MOS, Temperature sensing circuit, humidity sensing material and so on PM2.5, CO2, AQS, Temperature and humidity PM2.5:0~1000μg/m³ CO2:400~10000ppm AQS:CO: 1~5000ppm、NOx: 0~10ppm, NH3: 1~300ppm Temperature:-40~125℃ Humidity:0~100%RH CAN/LIN(Customizable)

Safety Product Line

Model Detection principle Detection object Detection range Output mode

ZC61
Catalytic combustion H2 0~40000ppm PWM/CAN/Analog quantity(Customizable)

ZC41
Catalytic combustion Natural gas, liquefied gas, coal gas, alkanes and other flammable gases 0~100%LEL PWM/CAN/Analog quantity(Customizable)

ZEQH-101
Planar semiconductor NDIR CO, CO2, VOC, temperature, pressure CO:0~1000ppm CO2:400~10000ppm VOC:200~10000ppm pressure:0~130kPa temperature:-40℃~200℃ CAN/LIN(Customizable)

ZPH07
Infrared light scattering Aerosol 0~10000μg/m³ CAN/LIN(Customizable)

ZW-HC101
Electrochemistry Coolant 0.01~20 uS/cm CAN/Analog quantity(Customizable)

Alcohol Detection Sensor
Electrochemistry Alcohol 0~440mg/100ml(0~2mg/L) CAN/LIN(Customizable)

Intelligence Product Line

Model Detection principle Detection object Detection range Output mode

ZH101
Total reflection of light Water & Light Rainfall:7*7mm(Rainfall detection area) Lighting directly above:1000~50000lx(Light intensity detection range) front light:1000~100000lx(Light intensity detection range) temperature:-40~85℃ humidity:0~100%RH CAN/LIN(Customizable)

ZH401
Photoelectric conversion Light 1500~6000lx Low level/ High resistance state(Customizable)

ZHMT101
Infrared thermopile NDIR Life form Detection field of view range:0.6*1.4*0.6m CO2:400~5000ppm temperature:-55~125℃ CAN/LIN(Customizable)

Anti-intrusion Sensor
Infrared pyroelectricity Life form Detection distance:3m temperature:-55~125℃ CAN/LIN(Customizable)

ARE YOU LOOKING FOR SENSOR

Not sure which sensor is right?

Get a free initial consultation right now

WHAT WE DO

Automotive Sensor Knowledge

Winsen vehicle sensor has passed IATF 16949 vehicle-level certification. We provide health-related in-vehicle air quality monitoring, hydrogen leakage detection, battery safety, and alcohol monitoring for automobiles with excellent performance, reliable quality and professional technical service.

Leading gas sensing Solution supplier

Our Hot Products

ANY QUESTIONS?

Frequent Asked Questions

Professional manufacturer of gas sensors, global sensing solutions provider with over 30 years of experience. Top quality guarantee, Excellent service, Customized products, Fast delivery!

Reference lead times: 1-15 days after receiving deposit depending on volume. The actual lead time can be confirmed with Winsen Order Processing Dept.

Winsen will recommend the most appropriate way of transportation (express, air, sea, train, etc.) according to customer's requirement on cost and time.

T/T, Paypal, West Union, Credit Card, etc.

MOQ is different depending on product models. Please contact Winsen sales for details.

Customer LOGO and packing design are acceptable.
Customized design and function will be provided without extra charge (including molding fee).

Sample order is acceptable and the fees will be borne by buyer.

Winsen has a complete and strict flow for offline sensors: aging-reject defective-sampling inspection-issue reports-finished ingoing...outgoing.

All Winsen products go through strict inspections and tests to make sure they are 100% qualified before shipping out.

ppm: parts per million
ppb: parts per billion
VOL: volume ratio
LEL: lower explosive limit
NDIR: Non-Dispersive Infra-Red
