ZPH05 Micro-dust Sensor
ZPH05 Micro-dust Sensor
  • Micro-dust
  • Read More
ZRT510 Refrigerant Sensor Module
ZRT510 Refrigerant Sensor Module
  • R454B
  • Read More
ZP211 Refrigerant gas detection module
ZP211 Refrigerant gas detection module
  • Refrigerant gas R290
  • Read More
ZP101 Burnt Smell Detection Module
ZP101 Burnt Smell Detection Module
  • Food burnt gas
  • 820~1300(10ppm alcohol) (20℃-26℃/30%RH~70%RH)
  • Read More
ZS21 Temperature and Humidity Sensor Module
ZS21 Temperature and Humidity Sensor Module
  • Temperature and Humidity
  • Read More
MH-Z1542B-R32 Refrigerant Sensor Module
MH-Z1542B-R32 Refrigerant Sensor Module
  • Refrigerant
  • 0~5.00% Vol
  • Read More
Multi-in-One ZPHS01B Sensor Module
Multi-in-One ZPHS01B Sensor Module
  • CO2. PM2.5. CH2O. O3. CO. TVOC. NO2. Temperature. Humidity
  • See Manul
  • Read More
ZH07 Laser dust sensor
ZH07 Laser dust sensor
  • PM1.0,PM2.5,PM10
  • 0-1000μg/m³
  • Read More
ZH03B Laser Dust Sensor Module
ZH03B Laser Dust Sensor Module
  • PM1.0,PM2.5,PM10
  • 0-1000μg/m³
  • Read More
ZPH04 Particles Sensor
ZPH04 Particles Sensor
  • PM2.5
  • Read More
WHT20B MEMS type Temperature and Humidity Sensor
WHT20B MEMS type Temperature and Humidity Sensor
  • Environment relative humidity,temperature
  • Read More
Electrochemical Ozone Detection Module ZE27-O3
Electrochemical Ozone Detection Module ZE27-O3
  • O3
  • 0~10ppm
  • Read More
Electrochemical Ozone Detection Module ZE25-O3
Electrochemical Ozone Detection Module ZE25-O3
  • O3
  • 0~10ppm
  • Read More
Electrochemical Carbon Monoxide Gas Module ZE15-CO
Electrochemical Carbon Monoxide Gas Module ZE15-CO
  • CO
  • 0~500ppm
  • Read More
Electrochemical Ozone Detection Module ZE14-O3
Electrochemical Ozone Detection Module ZE14-O3
  • O3
  • 0~100ppm
  • Read More
Electrochemical CH2O Detection Module ZE08-CH2O
Electrochemical CH2O Detection Module ZE08-CH2O
  • CH2O
  • 0~5ppm
  • Read More
ZP14 Combustible Gas Detection Module
ZP14 Combustible Gas Detection Module
  • Natural gas,CH4
  • 0-5000PPM,Resolution 50PPM
  • Read More
ZP07 Air-Quality Detection Module
ZP07 Air-Quality Detection Module
  • formaldehyde, benzene, carbon monoxide, hydrogen, alcohol, ammonia, smoke of cigarette, essence &etc.
  • Output 0-3 grade pollution signal
  • Read More
MH-Z19E NDIR CO2 Module
MH-Z19E NDIR CO2 Module
  • CO2
  • 400~10000ppm optional
  • Read More
MH-Z19C NDIR CO2 Module
MH-Z19C NDIR CO2 Module
  • CO2
  • 400~10000ppm optional
  • Read More
ZRD-09 PIR Motion Sensor Module
ZRD-09 PIR Motion Sensor Module
  • Induction signal
  • Read More
MQ-2 Semiconductor Sensor for Flammable Gas
MQ-2 Semiconductor Sensor for Flammable Gas
  • Flammable gas,Smoke
  • 300-10000ppm(Flammable gas)
  • Read More
GM-802B MEMS NH3 Gas Sensor
GM-802B MEMS NH3 Gas Sensor
  • NH3
  • 1-300ppm
  • Read More

Help you compare our sensors

Table Overview for Winsen Household Appliances

Unsure which sensor to choose, please leave your infomation or email us

Modle Detection principle Characteristics Target gas Detection range Size

ZPH05
Principle of optical contrast Accurately identify different particles,Output the number of particles Micro-dust 24.52×24.22×8.3 (mm)

ZRT510
NDIR High sensitivity, high resolution, fast response R454B 75.4*57*21.5 mm (without connecting cable)

ZP211
Module,semiconductor High sensitivity,fast response,strong anti-interference ability Refrigerant gas R290 25×34×14.1mm(L×W×H)

ZP101
Semiconductor Fast response, support serial communication Food burnt gas 820~1300(10ppm alcohol) (20℃-26℃/30%RH~70%RH) 43.0mm×26.0mm×15.9mm (L×W×H)

ZS21
Semiconductor,Modle Fully calibrated,Wide power supply voltage range, from 2.0V to 5.5V,Digital output, standard I²C signal Temperature and Humidity

MH-Z1542B
non-dispersive infrared (NDIR) High sensitivity, high resolution, fast response,UART output Refrigerant 0~5.00% Vol 32.9x22.3x11.9mm

ZPHS01B
Module See Manul CO2. PM2.5. CH2O. O3. CO. TVOC. NO2. Temperature. Humidity See Manul 135 x 50 x 26.2mm (L x W x H)

ZH07
Laser Good consistency,Real time response,Low power consumption,RESET compliant PM1.0,PM2.5,PM10 0-1000μg/m³ 48×40×12.5mm(L×W×H)

ZH03B
Laser Good consistency, Real time response PM1.0,PM2.5,PM10 0-1000μg/m³ 50x32.4x21mm(LxWxH)

ZPH04
IR Good Stability for long time,Easy to install and use PM2.5 59.5×44.5×20mm(L×W×H)

WHT20B
MEMS capacitive humidity sensor 1、High accuracy ±3.0% RH and ±0.5℃;2、Wide power supply voltage range, from 2.0V to 5.5V;3、SMD package suitable for reflow soldering;4、Quick response and strong anti-interference ability;5、Excellent long-term stability under high humidity condition Environment relative humidity,temperature

ZE27-O3
Module, electrochemical Portable O3 detector, air-quality monitor device, Ozone disinfection cabinet, smart home device, etc. O3 0~10ppm 17.1x19.2x4.5mm

ZE25-O3
Module, electrochemical Portable O3 detector, air-quality monitor device, Ozone disinfection cabinet, smart home device, etc. O3 0~10ppm 23x25.5x4.4mm

ZE15-CO
Module, electrochemical Household CO alarm gas, smart home devices. CO 0~500ppm 25.4x22.4x18.3mm

ZE14-O3
Module, electrochemical Ozone disinfection cabinet, smart home devices, etc. O3 0~100ppm 22x26x18.2mm

ZE08-CH2O
Module,electrochemical Portable detector, air-quality monitor, air cleaner, air renewal system, air conditioner, smart home. CH2O 0~5ppm 23x25x4.4mm

ZP14
Module,semiconductor Complete device development of household gas leak alarm. Natural gas,CH4 0-5000PPM,Resolution 50PPM 25×21.1×15

ZP07
Module,semiconductor High sensitivity,excellent long term stability, calibrated before shipment 10 seconds to 3 minutes with auto-preheating function Faulty auto-check formaldehyde, benzene, carbon monoxide, hydrogen, alcohol, ammonia, smoke of cigarette, essence &etc. Output 0-3 grade pollution signal 24×20×16

MH-Z19E
non-dispersive infrared (NDIR) principle 1. High sensitivity, low power consumption; 2, Good stability; 3. Temperature compensation, excellent linear output; 4. Multiple output modes: UART, PWM; 5.RESET compliant CO2 400~10000ppm optional 32.9x19.7x8.6mm (LxWxH)

MH-Z19C
non-dispersive infrared (NDIR) principle 1. Chamber is gold plated; 2. High sensitivity, low power consumption; 3. Good stability; 4. Temperature compensation, excellent linear output;5.RESET compliant CO2 400~10000ppm optional 32.9x19.7x8.6mm(LxWxH)

ZRD-09
pyroelectric effect 1、Automatic Induction;2、Photo-resistor control;3、Two trigger modes;4、Induction blocking time;5、High-level output Induction signal 32mm*24mm*24mm

MQ-2
Semiconductor Has high sensitivity to C3H8 and smoke Flammable gas,Smoke 300-10000ppm(Flammable gas) φ19×24.2

GM-802B
Semiconductor、MEMS High sensitivity to NH3 NH3 1-300ppm 5×5×1.55

ARE YOU LOOKING FOR SENSOR

Not sure which sensor is right?

Get a free initial consultation right now

WHAT WE DO

Household Appliances Knowledge

Keeping low CO2 level is important for human health, which not only means that the current environment has sufficient fresh air, but also greatly reduce the risk of building syndrome. Winsen CO2 sensor meets RESET standard, which is widely used in control panels or thermostats for HVAC systems.

Leading gas sensing Solution supplier

Our Hot Products

ANY QUESTIONS?

Frequent Asked Questions

Professional manufacturer of gas sensors, global sensing solutions provider with over 30 years of experience. Top quality guarantee, Excellent service, Customized products, Fast delivery!

Reference lead times: 1-15 days after receiving deposit depending on volume. The actual lead time can be confirmed with Winsen Order Processing Dept.

Winsen will recommend the most appropriate way of transportation (express, air, sea, train, etc.) according to customer's requirement on cost and time.

T/T, Paypal, West Union, Credit Card, etc.

MOQ is different depending on product models. Please contact Winsen sales for details.

Customer LOGO and packing design are acceptable.
Customized design and function will be provided without extra charge (including molding fee).

Sample order is acceptable and the fees will be borne by buyer.

Winsen has a complete and strict flow for offline sensors: aging-reject defective-sampling inspection-issue reports-finished ingoing...outgoing.

All Winsen products go through strict inspections and tests to make sure they are 100% qualified before shipping out.

ppm: parts per million
ppb: parts per billion
VOL: volume ratio
LEL: lower explosive limit
NDIR: Non-Dispersive Infra-Red
