Target: Aerosol
Model: ZPH07
Detection range: 0~10000μg/m³
Detection principle: Infrared light scattering
Output signal: CAN/LIN(Customizable)
Notes: IATF16949 compliant

Get Price Whatsapp


ZPH07 is installed in the lithium battery pack. It uses the principle of infrared light scattering to monitor the aerosol (particulate matter) data in the battery pack in real time, and transmits the monitoring values ​​to the vehicle battery management system (BMS), with accurate measurement, fast response, low power consumption, long life and high reliability.


Monitor thermal runaway events in lithium-ion battery packs and energy storage system of electric automobile


  • Smart monitoring
  • Fast response
  • Low consumption and high efficiency


Thermal Runaway Aerosol Monitoring Sensor
Detection principle Infrared light scattering
Detection target Aerosol
Detection range 0~10000μg/m³
Detection accuracy The threshold concentration is 5000μg/m³,≤±15%
Operating voltage DC (9~16)V
Operating current <30mA
Quiescent Current <0.5mA
Operating temperature  -40℃~85℃
Storage temperature  -40℃~85℃
Output mode CAN/LIN(Customizable)

* The description and specifications might be changed without notice. Please contact us for the latest information before placing orders.

Technical Support:

Customized technical design and function, LOGO and package are available without extra charge (including molding fee) for mass volume.

The sensors don't have sleeping mode. It can be set in program if needed.

All Winsen products go through strict inspections and tests to make sure they are 100% qualified before shipping out.

The sensor has been fully tested (not calibrated) before leaving the factory. However, after transportation and storage, the environment conditions change, and the surface of the sensor absorbs moisture, mixed gas, pollution matters, etc. It is recommended that customers perform aging and calibration after sensors become stable according to the program and use occasions of the whole device.

15﹪-90﹪RH without condensation,greater or less than this range or long-term high temperature and high humidity will affect the life of the sensor.

Our sensors are certified with CE, 3C, ROHS, anti-explosion, fire prevention, and coal mining safety according to different applications. And we provide assistance for new certification.

Many factors can cause the sensor to fail such as broken wires in transportation, poisoning, falling off of the sensitive material, damage to the heating wire (device), etc. Please find specific cause in each category with Winsen’s aftersales.
