Description
The MH-T8041A laser methane gas sensor is a high-precision gas sensor based on Tunable Diode Laser Absorption Spectroscopy (TDLAS). This sensor features stable performance, long service life, and high sensitivity. With advanced data processing, the sensor offers faster response speed, higher sensitivity, and lower power consumption, continuously monitoring methane concentration in the air and transmitting real-time data.
The product is manufactured in accordance with national standards GB/T 3836.1-2021 Explosive atmospheres – Part 1: Equipment – General requirements and GB/T 3836.4-2021 Explosive atmospheres – Part 4: Equipment protection by intrinsic safety "i". It is suitable for use in Zone 1 and Zone 2 hazardous locations where explosive mixtures of flammable gases or vapors with air of Class IIA~IIC and temperature groups T1~ T6 may exist.
Application
- Coal mine Safety Monitoring
Features
- Fast response
- High accuracy, high sensitivity
- Excellent stability
- No drift, no calibration required during service life
- High reliability, anti-reference(non-target gas does not react)
- Digital communication interface
Specifications
| Table1 | ||||
| Target Gas | Methane (CH4) | |||
| Principle | Laser | |||
| Workingvoltage | 3.3 | 5 | 5.5 | V |
| Average Current (room temperature) | 65 | 65 | / | mA |
| Operating Current(instantaneous) | / | ≤180 | / | mA |
| MeasuringRange | 0-100.00%VOL | |||
| Resolution | 0.01%VOL | |||
| ResponseTime | < 15s | |||
| OperatingTemperature | - 10-50℃ | |||
| OperatingHumidity | 0~95%RH(non-condensing) | |||
| OperatingPressure | 80kPa~116kPa | |||
| StorageTemperature | -40℃~85℃ | |||
| Indicating Error | 0.05%VOL-1.00%VOL ±(0.06%VOL) 1.00%VOL-100.00%VOL (±6%of true value)@25℃ | |||
| ServiceLife | > 5Years | |||
| CommunicationInterface | UART@3V | |||
| HousingMaterial | 304StainlessSteel | |||
| LaserOpticalPower | Radiantpower≤15mW | |||
| ExplosionProtectionRating | Ex ia IMa | |||
| Intrinsicallysafeparametersforpowerandsignalterminals:Ui: 5.5VDC, Ii: 500 mA, Pi: 0.688 W, Ci: 16.2 μF,Li: 1.2 μH. | ||||
* The description and specifications might be changed without notice. Please contact us for the latest information before placing orders.
Technical Support:
Customized technical design and function, LOGO and package are available without extra charge (including molding fee) for mass volume.
The sensors don't have sleeping mode. It can be set in program if needed.
All Winsen products go through strict inspections and tests to make sure they are 100% qualified before shipping out.
The sensor has been fully tested (not calibrated) before leaving the factory, but the module will be calibrated before leaving the factory.
However, after transportation and storage, the environment conditions change, and the surface of the sensor absorbs moisture, mixed gas, pollution matters, etc. It is recommended that customers perform aging and calibration after sensors become stable according to the program and use occasions of the whole device.
15﹪-90﹪RH without condensation,greater or less than this range or long-term high temperature and high humidity will affect the life of the sensor.
Our sensors are certified with CE, 3C, ROHS, anti-explosion, fire prevention, and coal mining safety according to different applications. And we provide assistance for new certification.
Many factors can cause the sensor to fail such as broken wires in transportation, poisoning, falling off of the sensitive material, damage to the heating wire (device), etc. Please find specific cause in each category with Winsen’s aftersales.
